Dimension LxWxH(mm)
170*66*39MM
Meet IEC 60950-1
Over Current Protection
Meet Energy Efficiency DOE Level VI
Over Temperature Protection
Meet Code of Conduct Version 5 Tier 2
Over Voltage Protection
High Reliability
Electronic Short Circuit Protection
EMC Standard: EN55032/EN55024 Class B
Click here, you will get more details.
InquireModel | SD1210000 | SD1508000 | SD1856500 | SD2405000 | SD3603000 |
---|---|---|---|---|---|
Input Voltage | 100-240VAC | ||||
Input Frequency | 50/60Hz | ||||
Wattage | 120W | 120W | 120W | 120W | 108W |
Output Voltage | 12V | 15V | 18.5V | 24V | 36V |
Output Current | 10A | 8A | 6.5A | 5A | 3A |
Form Factor | Desktop Power Adapters | ||||
AC Inlet/Plug | C8,C14,C6 |
170*66*39MM
Our application is very extensive,such as Household,Appliances,Beauty Devices,Mobile Devices,Set-top-box,POS Machine,CCTV,LED,Networking Devices…
